Epson PLQ 35 Dot Matrix Passbook Printer
A 24-pin dot matrix passbook printer, designed as an economic solution, offering reliability, as well as fast printing and a modern design.
The PLQ-35 is a dot matrix printer that is affordable, ultra-reliable and has the capability to handle passbooks. The product is able to replicate previous emulations, which reduces the need for retraining.
- Affordable Cost effective alternative to other passbook printers
- Fast performance Prints up to 540 characters per second with 6+1 copies
- Reliable Significantly increased mean time between failure rate of 35,000 hours
- Compatible consumables Same long-lasting ribbons compatible with all models
- Design Improved, modern design
- Specialised Passbook Printer
- Print Speed: up to 540 cps (10 cpi)
- Mean print volume between failure (MVBF) of 21 million lines
- Mean time before failure (MTBF) of 30,000 POH
Printing
| Maximum print speed | 540 cps |
|---|---|
| Maximum resolution | 180 x 360 DPI |
| Maximum printing width (columns) | 94 |
| Maximum print speed (draft) | 360 cps |
| Maximum print speed (LQ) | 120 cps |
| Maximum print speed (NLQ) | 180 cps |
| Character pitch | 10 cpi |
| Maximum number of copies | 6 copies |
| Built-in barcodes | CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E |
| Bitmap fonts | Courier, Draft, OCR-B, Orator, Orator-S, Prestige, Roman, Sans Serif, Script, Script C |
| Scalable fonts | Roman T, Sans Serif H |
| Character sets | PCAPTEC, PC437, PC708, PC720, PC850, PC858, PC864, PCAR864, ISO 8859-15, Roman 8, Italic |
| Number of characters | 14 |
Paper handling
| Multi-part paper thickness range | 0.12 – 0.53 mm |
|---|---|
| Single sheet thickness range | 0.065 – 0.19 mm |
Features
| Colour | White |
|---|---|
| Buffer size | 128 KB |
| Sound pressure level (printing) | 55 dB |
| Page description languages | Epson ESC/P2, PPDS |
| Country of origin | Indonesia |
Ports & interfaces
| Standard interfaces | Parallel, RS-232, USB 2.0 |
|---|
Endurance
| Print head | 24-pin |
|---|---|
| Print head life | 400 million characters |
| Mean time between failures (MTBF) | 35000 h |
Power
| Power consumption (typical) | 61 W |
|---|---|
| Power consumption (standby) | 0.7 W |
| AC input voltage | 220-240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Operating temperature (T-T) | 5 – 38 °C |
|---|---|
| Storage temperature (T-T) | -30 – 60 °C |
| Operating relative humidity (H-H) | 10 – 85% |
Weight & dimensions
| Width | 384 mm |
|---|---|
| Depth | 280 mm |
| Height | 203 mm |
| Weight | 7.8 kg |
Packaging data
| Quantity per pack | 1 pc(s) |
|---|---|
| Package width | 365 mm |
| Package depth | 455 mm |
| Package height | 255 mm |
| Package weight | 9.27 kg |
Other features
| Print technology | Dot matrix |
|---|---|
| Needles | 24 (2 x 12) |
Technical details
| Harmonized System (HS) code | 84433210 |
|---|
Logistics data
| Products per pallet (UK) | 48 pc(s) |
|---|
