SCP 650VA UPS System

SCP 650VA UPS System

SPECIFICATIONS

Output
Output power capacity
325Watts / 650VA

Max Configurable Power (Watts)
325Watts / 650VA

Nominal Output Voltage
230V

Output Frequency (sync to mains)
50/60 Hz +/-1 Hz

Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave

Transfer Time
4ms typical : 6ms maximum

Input
Nominal Input Voltage
230V

Input frequency
50/60 Hz +/- 3 Hz (auto sensing)

Input Connections
NEMA 5-15P

Cord Length
1.22meters

Input voltage range for main operations
180 – 270V

Number of Power Cords
1

Type of Input Protection Required
gL fuse

Maximum Input Current
5.0A

Input Power Factor at Full Load
0.5

Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Included Battery Modules
1

Typical recharge time
4hour(s)

SCP Line-Interactive 650VA UPS
Power Backup Solution
Provides uninterruptible power to your sensitive PC systems

Cost-Efficient
A small investment will protect your valuable electronic equipment from the hazards of power interruption/failure.

Energy Saving
The UPS will automatically shut down when no load is connected.

• AVR Buck / Boost
• Cold start function
• Auto restart while AC is recovering
• Output short circuit & Overload protection
• Battery overcharge & Over-discharge protection
• Auto charging at off mode & fast charging capacity
